CO2 Tank Adapter - Male CGA 320 to Barb

Direct-Connect CGA 320 to Barb Adapter

Connect gas tubing directly to your CO2 supply with this male CGA 320 to barb adapter. It provides a straightforward link from your gas connection directly to high-pressure manifolds, custom transfer setups, or secondary regulation systems.

This fitting converts a standard male CGA 320 connection into a direct hose barb. You'll need to select either a 1/4-inch or 3/8-inch barb to match your gas line's internal diameter (ID). Once attached, the barbed end firmly grips your thermoplastic or PVC tubing. We strongly recommend securing the line with a stepless Oetiker clamp or a standard worm drive clamp to maintain a tight, leak-free seal under pressure.

The adapter stem is machined from stainless steel. This provides excellent resistance to corrosion, ensuring it holds up in high-humidity environments like walk-in coolers, commercial draft cellars, or active brewery floors. And because it is stainless steel, it won't degrade when exposed directly to CO2 over long periods.

Key Specifications

• Inlet: Male CGA 320
• Outlet: 1/4" or 3/8" Hose Barb
• Material: Stainless Steel
• Gas Compatibility: CO2

Highlights

• Converts male CGA 320 CO2 tank valves to barb hose connections.
• Available in 1/4 inch or 3/8 inch barb sizes.
• Stainless steel stem provides CO2 compatibility.
